Sibo занимается потенциометрами и датчиками уже 30 лет.

EI40NB
EI40NB

EI40NB

Incremental Encoders

瀏覽量: Вернуться: 2023-03-03

    Характеристики:

  • Magnetic encoders

  • Any PPR up to 4096 available

  • High protection degree

  • With one couple of precision ball bearings

  • With short-circuit proof

  • Flange mount

Измерение


Параметр

General Mechanical Specifications

Protection degree

IP65

Operating torque

≤1mN·m

Max.speed

6000rpm

Shaft load

Radial 60N,Axial 30N

Life expectancy

>2,000,000,000

Mass

Approx.120g

Housing material

Anodized aluminium alloy

Shaft material

Stainless steel

Environmental Specifications

Operating temperature range

-30℃~+85℃

Storage temperature range

-30℃~+85℃

General Electrical Specifications

Standard model

EI40NB-F1-W4096-P

Applied voltage

4.75V-30V or 5V for RS-422

Output high level

>VCC-2.5V

Output form

Differential push-pull incremental or RS-422 incremental

Number of output pulse

4096 ppr

Output propagation delay

<5μs

Current consumption (no-load)

≤30mA

Load current

Short-circuit, with A shorted B ≤80mA, Output current -220mA~220mA

Insulation resistance

>1000MΩ (500V.D.C)

Dielectric strength

1 min (500V.A.C)

Special Specifications Available

Special shaft

Special length of shaft、special diameter or special machining on shaft (like shaft slotted、fatted etc.)

Special Output

Differential signal products are available.
