Sibo занимается потенциометрами и датчиками уже 30 лет.

EBM50A
EBM50A

EBM50A

Absolute Multi-turn Encoders

瀏覽量: Вернуться: 2023-03-02

    Характеристики:

  • Magnetic encoders

  • Multi-turn: 4096 turns

  • High protection degree

  • With one couple of precision ball bearings

  • Output signal:RS485, CAN

  • Antimagnetic interference

Измерение


Параметр

General Mechanical Specifications

Protection degree

IP65

Staring torque

≤1mN·m

Life expectancy

>100,000,000

Mass

Approx.150g

Housing material

Anodized aluminium alloy

Shaft material

Stainless steel

Shaft load

≤30N

Shaft diameter

φ8, Front end milling

Environmental Specifications

Operating temperature range

-40℃~+85℃

Storage temperature range

-40℃~+85℃

Vibration

100m/s²,55Hz~2000Hz (EN 60068-2-6)

Shock

500m/s²,13ms (EN 60068-2-27)

ESD durability

Contact discharge ±8KV,Aerial discharge ±15KV,EN61000-4-2:2009

EMS durability

100V/m (80MHz~1GHz,1KHz80% Amplitude modulation),EN61000-4-3:2006+A1:2010

General Electrical Specifications(RS485)

Standard model

EBM50A-S2-W1212B485

Applied voltage

9V-30V

Current consumption

<80mA

Single-turn resolution

4096 (12 Bit)

Independent linearity tolerance

±0.3%

Repeatability accuracy

±1Lsb (The actual accuracy is related to the installation accuracy)

Protocol

Modbus RTU slave

Baud rate

1200~115200bps settable, Default 9600bps9600 bps

Address

Default 1, settable

Insulation resistance

>1000MΩ (500V.D.C)

Dielectric strength

1 min (500V.A.C)

General Electrical Specifications(CAN)

Standard model

EBM50A-S2-W1212BCAN

Applied voltage

10V-30V

Current consumption

<80mA

Single-turn resolution

4096 (12 Bit)

Number of turns

4096 Turns (12 Bit)

Independent linearity tolerance

±0.3%

Repeatability accuracy

±1Lsb (The actual accuracy is related to the installation accuracy)

Protocol

CANopen

Insulation resistance

>1000MΩ (500V.D.C)

Dielectric strength

1 min (500V.A.C)

Special Specifications Available

Special shaft

Special length of shaft、special diameter or special machining on shaft (like shaft slotted、fatted etc.)

Customized protocol

We can make customized protocol according to customers' requirements.
