Operating angle

Approx. ±20°（From center position）

Operating force

Approx. 4N～80N

Life expectancy

<5,000,000

Operating temperature

-20℃~+65℃

Storage temperature

-20℃~+65℃

Mass

Approx. 150g

Protection degree

IP65 (Above panel）

Standard resistance value

10K±15%

Independent linearity tolerance

±3%

Resolution

Essentially infinite

Dielectric strength

1 min (500V.A.C.)

Insulation resistance

>1000MΩ (500V.D.C.)

Power rating

0.1W

Electrical angle

Approx. 40°

Electrical specifications (switch)

Push button switch

Rating

48V.D.C. / 0.1A

Electrical life expectancy

1,000,000

Mechanical life expectancy

1,000,000

Insulation resistance

>1000MΩ (500V.D.C.)

Dielectric strength

1min (500V.A.C.)

Color

Red；Black；Green；White；Yellow

Title

VCC；GND；SW；X；Y

Special knob

Customized knob; with push button switch (with light is optional), Details please check "Other optional knobs"

Other special specifications

With DEUTSCH connector (6pin)；With control module
